NE724/726 Electro Pneumatic Valve Positioner

NE positioners

These electro-pneumatic positioners operate on a milliampere signal from a controller. They accurately position the control valve assembly in response to a change in input signal.

Metso valve positioner Neles NE724 electro pneumatic positioner is proportional positioners for control valves. NE724 valve positioner is an electro-pneumatic positioner that provides pneumatic output proportional to a standard milliampere DC input. Both units can be used with either cylinder or diaphragm type actuators for rotary or linear valves to provide excellent repeatability and accuracy in a wide range of throttling applications.

The nominal input resistance is 190 ohms. The moving force coil assembly has low mass and is accurately balanced to assure proper function even in severely vibrating applications. The dynamic behaviour of the positioner can be changed by choosing different size pilot valves.

FEATURES

Excellent vibration resistance

Rugged construction, few parts, small moving mass, compact design and rigid mounting provide outstanding vibration resistance.

Field reversible

Valve Positioner can be set for direct or reverse-acting modes by simply turning around the changeover piece and feedback cam without touching or changing tubings between actuator and positioner. Split-range and reverse actions are standard on the feedback cam.

Easy and fast to calibrate

Calibrations can be easily made with the positioner cover removed. You can fine-tune zero and range adjustments with minimal effect on set points.

Fast response times

Multiple pilot valve sizes are used to match positioner capacity compatibility with actuator stroke volume, minimizing response time.

Stable operation

Changes in supply pressure and valve load have minimal effect on positioner operation.

NE700 Electro Pneumatic Valve Positioner-Data Sheet (PDF Download)
